Image Sensor
1/2.9" Progressive Scan CMOS
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Lens Type
Fixed focal lens, 2.8 mm
Lens Mount
M12
Aperture
F1.6
Supplement Light Type
IR, White Light
Smart Supplement Light
Yes
Main Stream
Video Compression
H.264 Type
Baseline Profile, Main Profile, High Profile
Bit Rate Control
CBR, VBR
Audio Type
Mono sound
Audio Sampling Rate
8 kHz/16 kHz
Audio Bit Rate
Simultaneous Live View
Up to 6 channels
Protocols
Client
iVMS-4200, Hik-Connect
Wide Dynamic Range (WDR)
Digital WDR
Day/Night Switch
Day, Night, Auto, Schedule
Image Settings
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic Event
Power
12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 80
Dimension
Ø121.4 mm × 97.7 mm (Ø4.8" × 3.8")
Weight
Approx. 550 g (1.2 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
General Function
Heartbeat, anti-banding, mirror, password protection, password reset via email
Safety
Protection
IP67: IEC 60529-2013, IK08: IEC 62262:2002
Max. Resolution
1920 × 1080
Min. Illumination
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Angle Adjustment
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Focal Length & FOV
2.8 mm, horizontal FOV 103°, vertical FOV 56°, diagonal FOV 121°
Iris Type
Fixed
DORI
2.8 mm, D: 45 m, O: 18 m, R: 9 m, I: 4 m
Supplement Light Range
Up to 30 m
IR Wavelength
850 nm
Sub-Stream
Video Bit Rate
32 Kbps to 8 Mbps
H.265 Type
Main Profile
Region of Interest (ROI)
1 fixed region for main stream
Environment Noise Filtering
Yes
Audio Compression
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Security
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE
API
User/Host
Web Browser
SNR
? 52 dB
Image Enhancement
BLC, HLC, 3D DNR
Privacy Mask
4 programmable polygon privacy masks
Built-in Microphone
Yes
Linkage
Material
Metal & Plastic
Package Dimension
150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
With Package Weight
Approx. 800 g (1.8 lb.)
Language
Polish
EMC
Environment
